1975-1991 Chevy Small Block SBC V8 262 265 283 305 327 350 400 Shorty Exhaust Header Black
Description
This Block Hugger style header is meant to be used where space for long tube headers isn’t available due to steering and cross-member clearance issues. Tubing has been optimized for the 5.0L (305ci), 5.3L (327ci), 5.7L (350ci), and 6.6L (400ci) engines. This reduces cylinder backpressure and improves exhaust gas velocity.
Features
- Inlet/ Outlet: 1.5"/ 2.5"
- Primary Diameter: 1-1/2 in.
- Collector Diameter: 2-1/2 in.
- Head Flange Thickness：3/8 in. (9.5mm)
- Pipe Thickness: 16 gauge (1.5mm)
- Reducer and Metal Gasket Included
- 3-Bolt Flange
- TIG Welded CNC Machine Flange
- Professional Installation is Highly Recommended
- Installation Instruction is not Included
Fitment
- Fits All Small Block Chevy V8 Engines from '55+ using the Standard Exhaust Pattern - 283, 305, 327, 350, 400 etc.
| VEHICLE NAME | YEAR | ENGINE |
|---|---|---|
| Chevrolet Blazer | 1987~1991 | 5.0L|5.7L |
| Chevrolet C10 | 1975~1986 | 5.0L|5.7L|6.6L |
| Chevrolet C10 Pickup | 1967~1968 | 5.0L|5.3L|5.4L |
| Chevrolet C10 Suburban | 1975~1986 | 5.0L|5.7L |
| Chevrolet C20 | 1975~1986 | 5.0L|5.7L|6.6L |
| Chevrolet C20 Pickup | 1967~1968 | 5.0L|5.3L|5.4L |
| Chevrolet C20 Suburban | 1975~1986 | 5.0L|5.7L|6.6L |
| Chevrolet C30 | 1975~1986 | 5.0L|5.7L|6.6L |
| Chevrolet C30 Pickup | 1967~1968 | 5.0L|5.3L|5.4L |
| Chevrolet K10 | 1982~1986 | 5.0L|5.7L |
| Chevrolet K10 Suburban | 1982~1986 | 5.0L|5.7L |
| Chevrolet K20 | 1982~1986 | 5.0L|5.7L |
| Chevrolet K20 Suburban | 1982~1986 | 5.0L|5.7L |
| Chevrolet K30 | 1982~1986 | 5.7L |
| Chevrolet K5 Blazer | 1975~1986 | 5.0L|5.7L|6.6L |
| Chevrolet R10 | 1987 | 5.0L|5.7L |
| Chevrolet R10 Suburban | 1987~1988 | 5.0L|5.7L |
| Chevrolet R1500 Suburban | 1989~1991 | 5.7L |
| Chevrolet R20 | 1987 | 5.0L|5.7L |
| Chevrolet R20 Suburban | 1987~1988 | 5.7L |
| Chevrolet R2500 Suburban | 1989~1991 | 5.7L |
| Chevrolet R30 | 1987~1988 | 5.7L |
| Chevrolet V10 | 1987 | 5.0L|5.7L |
| Chevrolet V10 Suburban | 1987~1988 | 5.7L |
| Chevrolet V1500 Suburban | 1989~1991 | 5.7L |
| Chevrolet V20 | 1987 | 5.7L |
| Chevrolet V20 Suburban | 1987 | 5.7L |
| Chevrolet V30 | 1988 | 5.7L |
| Chevrolet V3500 | 1989~1991 | 5.7L |
| GMC C15 | 1975~1978 | 5.0L|5.7L|6.6L |
| GMC C15 Suburban | 1975~1978 | 5.0L|5.7L |
| GMC C1500 | 1979~1986 | 5.0L|5.7L|6.6L |
| GMC C1500 Suburban | 1979~1986 | 5.0L|5.7L |
| GMC C25 | 1975~1978 | 5.0L|5.7L|6.6L |
| GMC C25 Suburban | 1975~1978 | 5.0L|5.7L|6.6L |
| GMC C35 | 1975~1978 | 5.0L|5.7L|6.6L |
| GMC C3500 | 1979~1986 | 5.0L|5.7L|6.6L |
| GMC Jimmy | 1975~1991 | 5.0L|5.7L|6.6L |
| GMC K1500 | 1982~1986 | 5.0L|5.7L |
| GMC K1500 Suburban | 1982~1986 | 5.0L|5.7L |
| GMC K25 Suburban | 1977~1978 | 5.0L|5.7L|6.6L |
Attention
Products on this site are for off-road/racing use only and are not legal for public roads where emissions laws apply.
Professional installation recommended. Removing emissions equipment (DPF, CAT, SCR, DOC) requires deleting related sensors and a compatible tuner to avoid engine codes.
Performance gains may vary—no guarantees.
